Pioneer TS-Q160C-VW 16.5cm Perfect Fit Component Speakers for Volkswagen, Seat and Skoda

The Pioneer TS-Q160C-VW is a Perfect Fit 16.5cm 2-way component speaker system designed for selected Volkswagen, Seat and Skoda vehicles.

Part of Pioneer’s TS-Q Perfect Fit speaker range, this vehicle-specific speaker upgrade is designed to improve sound quality while keeping installation as straightforward as possible. All required fitting parts are included in the box, including OEM-style plug-and-play connectors, vehicle-specific brackets, tweeter connector cables, cushions, crimp sleeves, rivets and a step-by-step installation manual.

The TS-Q160C-VW is ideal for customers looking for a Pioneer sound upgrade over standard factory speakers. The component speaker design separates the woofer and tweeter, helping improve sound positioning, vocal clarity and overall detail compared with many factory speaker systems.

Pioneer’s OPEN & SMOOTH™ sound concept helps create a seamless transition between the midrange and tweeter, delivering a wide, natural and expansive soundstage. The IMPP™ cone is rigid and lightweight, helping improve clarity and reduce distortion for a cleaner, more detailed sound.

With 350W maximum power, 50W nominal input power, 92dB sensitivity and 4 Ohm impedance, the Pioneer TS-Q160C-VW is a strong factory speaker upgrade for selected Volkswagen, Seat and Skoda vehicles without needing a universal speaker fitting approach.

Vehicle Compatiblity

Designed for selected vehicles from:

• Volkswagen
• Seat
• Skoda

Please download the manual or scan the QR code to view the full list of compatible vehicles and the step-by-step installation manual.

Key Features

• Pioneer TS-Q160C-VW Perfect Fit speaker kit
• TS-Q vehicle-specific speaker upgrade
• 16.5cm 2-way component speaker system
• Designed for Volkswagen vehicles
• Designed for Seat vehicles
• Designed for Skoda vehicles
• 350W maximum input power
• 50W nominal input power
• Pioneer sound upgrade over factory speakers
• Pioneer OPEN & SMOOTH™ sound concept
• IMPP™ cone for improved clarity and reduced distortion
• 30mm Polyester Tetoron soft dome tweeter
• Component speaker design for improved detail and sound positioning
• Includes OEM-style plug-and-play connectors
• Includes vehicle-specific brackets
• Includes required fitting accessories
• Includes step-by-step installation manual
• Scan the QR code or download the manual for the full compatible vehicle list

Speaker Specifications

• Speaker type: 2-way component system
• Speaker size: 16.5cm
• Series: Pioneer TS-Q / Perfect Fit
• Maximum input power: 350W
• Nominal input power: 50W
• Frequency response: 27Hz-37,000Hz
• Sensitivity: 92dB
• Impedance: 4 Ohm
• Tweeter diameter: 30mm
• Dimensions: 165mm x 30mm
• Woofer mounting depth: 30mm
• Woofer magnet: Ferrite
• Tweeter magnet: Neodymium
• Woofer material: Injection Molded Polypropylene IMPP™ cone
• Tweeter material: Polyester Tetoron soft dome tweeter
• Speaker grille: Not included
• Weight: 1.51kg

What's in the box?

• Rivet x8
• Woofer cushion x2
• Tweeter connector cable Type A x2
• Tweeter connector cable Type B x2
• Crimp sleeve x4
• Tweeter bracket x2
• Tweeter fixing cushion x2
• Connector fixing cushion x2
• Cable cushion x1
• OEM-style connectors
• Vehicle-specific brackets
• Step-by-step installation manual

Installation Notes

The TS-Q160C-VW is designed as a Perfect Fit component speaker upgrade with vehicle-specific installation parts included in the box.

The included OEM-style connectors and brackets help make installation cleaner than a universal speaker upgrade. Compatibility depends on the exact vehicle model, year, trim level and original speaker system fitted.

Please Note

Designed for selected Volkswagen, Seat and Skoda vehicles. Download the manual or scan the QR code to confirm compatibility before ordering.
