Pioneer TS-Q160F-FD 16.5cm Perfect Fit Coaxial Speakers for Ford, Jaguar, Land Rover, Mazda

The Pioneer TS-Q160F-FD is a Perfect Fit 16.5cm 2-way coaxial speaker system designed for selected Ford, Jaguar, Land Rover and Mazda vehicles.

Part of Pioneer’s TS-Q Perfect Fit speaker range, this vehicle-specific speaker upgrade is designed to improve sound quality while keeping installation as straightforward as possible. All required fitting parts are included in the box, including OEM-style plug-and-play connectors, vehicle-specific brackets, woofer connector cables, woofer cushions, front woofer cushions, screws, rivets and a step-by-step installation manual.

The TS-Q160F-FD is ideal for customers looking for a Pioneer sound upgrade over standard factory speakers. The coaxial speaker design combines the tweeter and mid-bass driver into one speaker assembly, helping deliver a well-balanced combination of vocals, detail and bass without requiring a separate tweeter installation.

Pioneer’s OPEN & SMOOTH™ sound concept helps create a seamless transition between the midrange and tweeter, producing a wide, natural and expansive soundstage. The IMPP™ composite cone is rigid and lightweight, helping improve clarity and reduce distortion compared with many factory speaker systems.

With 350W maximum power, 50W nominal input power, 93dB sensitivity and 4 Ohm impedance, the Pioneer TS-Q160F-FD is a strong factory speaker upgrade for selected Ford, Jaguar, Land Rover and Mazda vehicles without needing a universal speaker fitting approach.

Vehicle Compatiblity

Designed for selected vehicles from:

• Ford
• Jaguar
• Land Rover
• Mazda

The included connector is suitable for selected Ford, Jaguar, Land Rover and Mazda vehicle applications.

Please download the manual or scan the QR code to view the full list of compatible vehicles and the step-by-step installation manual.

Key Features

• Pioneer TS-Q160F-FD Perfect Fit speaker kit
• TS-Q vehicle-specific speaker upgrade
• 16.5cm 2-way coaxial speaker system
• Designed for Ford vehicles
• Designed for Jaguar vehicles
• Designed for Land Rover vehicles
• Designed for Mazda vehicles
• 350W maximum input power
• 50W nominal input power
• Pioneer sound upgrade over factory speakers
• Pioneer OPEN & SMOOTH™ sound concept
• IMPP™ composite cone for improved clarity and reduced distortion
• Built-in tweeter and mid-bass driver
• Well-balanced vocals, detail and bass
• PEI tweeter material
• Ferrite woofer magnet
• Neodymium tweeter magnet
• Includes OEM-style plug-and-play connectors
• Includes vehicle-specific brackets
• Includes required fitting accessories
• Includes step-by-step installation manual
• Scan the QR code or download the manual for the full compatible vehicle list

Speaker Specifications

• Speaker type: 2-way coaxial system
• Speaker size: 16.5cm
• Series: Pioneer TS-Q / Perfect Fit
• Maximum input power: 350W
• Nominal input power: 50W
• Frequency response: 28Hz-30,000Hz
• Sensitivity: 93dB
• Impedance: 4 Ohm
• Dimensions: 165mm x 42mm
• Woofer mounting depth: 42mm
• Woofer material: Injection Molded Polypropylene IMPP™ cone
• Tweeter material: PEI
• Woofer magnet: Ferrite
• Tweeter magnet: Neodymium
• Speaker grille: Not included
• Weight: 1.50kg

What's in the box?

• Screw x6
• Rivet x6
• Woofer connector cable x2
• Woofer cushion x2
• Woofer cushion front x2
• OEM-style connectors
• Vehicle-specific brackets
• Step-by-step installation manual

Installation Notes

The TS-Q160F-FD is designed as a Perfect Fit coaxial speaker upgrade with vehicle-specific installation parts included in the box.

The included OEM-style connectors and brackets help make installation cleaner than a universal speaker upgrade. Compatibility depends on the exact vehicle model, year, trim level and original speaker system fitted.

Please Note

Designed for selected Ford, Jaguar, Land Rover and Mazda vehicles. Download the manual or scan the QR code to confirm compatibility before ordering.
